Damped rotation level switch

1.Brief introduction

It is material level controller for solid material, including powder, block, particle material. It has features of fine sealing property, strong overload capacity, simple, light weight and large output contacting capacity. All contacting parts adopt stainless steel material. And it is widely applied in chemical, plastic, cement, pharmaceutical, feed and food industry.

2.Product features

America professional technology, 3 bearing support and reliable running;
Special sealing design to prevent dust leakage;
Reliable and stable torsion;
Blade bears overload, clutch automatically slip, to protect engine;
Mechanical and electrical separated structure;

3.Technical index
1. power supply: 220VAC /110VAC/24VAC/24VDC
2. contact capacity: 250VAC/10A SPDT
3. power: 4W
4. rotating speed of blade: 1RPM
5. moment of force: 1.0kg×cm
6. proportion of material: ≥0.5g/cm3
7. operating temperature: -10℃-80℃
8. insulation resistance: ≥100MΩ
9. dielectric strength: 1500V*1min
10. level of protection: IP65
11. blade material: SUS304
